COMPANDING LAW:  A/MU-LAW

FILTER:  YES

JESD-30 CODE:  R-PQCC-J32

JESD-609 CODE:  E0

LENGTH:  13.97 MM

LINEAR CODING:  NOT AVAILABLE

MANUFACTURER:  AMD

MANUFACTURER PART NUMBER:  AM79C03JC

NEG SUPPLY VOLTAGE-NOM:  -5 V

NUMBER OF FUNCTIONS:  1

NUMBER OF TERMINALS:  32

OPERATING TEMPERATURE-MAX:  70 °C

OPERATING TEMPERATURE-MIN:  0 °C

PACKAGE BODY MATERIAL:  PLASTIC/EPOXY

PACKAGE CODE:  QCCJ

PACKAGE DESCRIPTION:  QCCJ, LDCC32,.5X.6

PACKAGE EQUIVALENCE CODE:  LDCC32,.5X.6

PACKAGE SHAPE:  RECTANGULAR

PACKAGE STYLE:  CHIP CARRIER

PART PACKAGE CODE:  QFJ

PEAK REFLOW TEMPERATURE (CEL):  NOT SPECIFIED

PIN COUNT:  32

POWER SUPPLIES:  +-5 V

QUALIFICATION STATUS:  NOT QUALIFIED

SEATED HEIGHT-MAX:  3.556 MM

SUBCATEGORY:  CODECS

SUPPLY VOLTAGE-NOM:  5 V

SURFACE MOUNT:  YES

TECHNOLOGY:  CMOS

TELECOM IC TYPE:  TIME SLOT ASSIGNER

TEMPERATURE GRADE:  COMMERCIAL

TERMINAL FINISH:  TIN/LEAD (SN/PB)

TERMINAL FORM:  J BEND

TERMINAL PITCH:  1.27 MM

TERMINAL POSITION:  QUAD

TIME@PEAK REFLOW TEMPERATURE-MAX (S):  NOT SPECIFIED

WIDTH:  11.43 MM
