209-3MST

209-3MST

DIP SWITCH SPST 3 POSITION THROUGH HOLE SLIDE (STANDARD) ACTUATOR 100MA 20VDC

Call for availability

Manufactured by:

CTS CORPORATION

Mfr Part#:  209-3MST

PACKAGING:  TUBE

Availability

  • Qty in Stock: Call for availability

  • Min. Order Qty: 1

SPECIFICATION

ACTUATOR LEVEL:  RAISED

ACTUATOR TYPE:  SLIDE (STANDARD)

CATEGORIES:  SWITCHES

CIRCUIT:  SPST

CONTACT FINISH:  GOLD

CONTACT MATERIAL:  BERYLLIUM COPPER

CURRENT RATING:  100MA

DETAILED DESCRIPTION:  DIP SWITCH SPST 3 POSITION THROUGH HOLE SLIDE (STANDARD) ACTUATOR 100MA 20VDC

ELECTRICAL LIFE:  2,000 CYCLES

FEATURES:  EPOXY SEALED TERMINALS, TAPE SEAL

HEIGHT ABOVE BOARD:  0.190" (4.83MM)

LENGTH:  0.358" (9.09MM)

MANUFACTURER:  CTS ELECTROCOMPONENTS

MANUFACTURER PART NUMBER:  209-3MST

MANUFACTURER STANDARD LEAD TIME:  12 WEEKS

MOUNTING TYPE:  THROUGH HOLE

NUMBER OF POSITIONS:  3

OPERATING TEMPERATURE:  -40°C ~ 85°C

PACKAGING:  TUBE

PITCH:  0.100" (2.54MM), FULL

SERIES:  209

TERMINATION STYLE:  PC PIN

VOLTAGE RATING:  20VDC

WASHABLE:  YES
