CATEGORIES:  DISCRETE SEMICONDUCTOR PRODUCTS

CURRENT - CONTINUOUS DRAIN (ID) @ 25°C:  200MA (TA)

DRAIN TO SOURCE VOLTAGE (VDSS):  60V

DRIVE VOLTAGE (MAX RDS ON, MIN RDS ON):  4.5V, 10V

EXPANDED DESCRIPTION:  N-CHANNEL 60V 200MA (TA) 400MW (TA) THROUGH HOLE TO-92-3

FET TYPE:  N-CHANNEL

INPUT CAPACITANCE (CISS) (MAX) @ VDS:  50PF @ 25V

LEAD FREE STATUS / ROHS STATUS:  LEAD FREE / ROHS COMPLIANT

MANUFACTURER:  FAIRCHILD/ON SEMICONDUCTOR

MANUFACTURER PART NUMBER:  2N7000_D26Z

MANUFACTURER STANDARD LEAD TIME:  8 WEEKS

MOISTURE SENSITIVITY LEVEL (MSL):  1 (UNLIMITED)

MOUNTING TYPE:  THROUGH HOLE

OPERATING TEMPERATURE:  -55°C ~ 150°C (TJ)

PACKAGE / CASE:  TO-226-3, TO-92-3 (TO-226AA) (FORMED LEADS)

PACKAGING:  REEL

POWER DISSIPATION (MAX):  400MW (TA)

RDS ON (MAX) @ ID, VGS:  5 OHM @ 500MA, 10V

STANDARD PACKAGE:  1

SUPPLIER DEVICE PACKAGE:  TO-92-3

TECHNOLOGY:  MOSFET (METAL OXIDE)

VGS (MAX):  ±20V

VGS(TH) (MAX) @ ID:  3V @ 1MA
