APPLICATIONS:  AUTOMOTIVE, GENERAL PURPOSE, INDUSTRIAL

CATEGORIES:  CONNECTORS, INTERCONNECTS

CONNECTOR TYPE:  HEADER

CONTACT FINISH - MATING:  TIN

CONTACT FINISH - POST:  TIN

CONTACT FINISH THICKNESS - MATING:  137.8ΜIN (3.50ΜM)

CONTACT LENGTH - POST:  0.169" (4.30MM)

CONTACT SHAPE:  CIRCULAR

CONTACT TYPE:  MALE PIN

EXPANDED DESCRIPTION:  9 POSITIONS HEADER CONNECTOR 0.250" (6.35MM) THROUGH HOLE TIN

FASTENING TYPE:  LOCKING RAMP

INSULATION COLOR:  NATURAL

INSULATION HEIGHT:  0.550" (13.97MM)

INSULATION MATERIAL:  POLYBUTYLENE TEREPHTHALATE (PBT)

LEAD FREE STATUS / ROHS STATUS:  LEAD FREE / ROHS COMPLIANT

MANUFACTURER:  MOLEX, LLC

MANUFACTURER PART NUMBER:  0010845090

MANUFACTURER STANDARD LEAD TIME:  10 WEEKS

MATERIAL FLAMMABILITY RATING:  UL94 V-0

MOISTURE SENSITIVITY LEVEL (MSL):  1 (UNLIMITED)

MOUNTING TYPE:  THROUGH HOLE

NUMBER OF POSITIONS:  9

NUMBER OF POSITIONS LOADED:  ALL

NUMBER OF ROWS:  3

PACKAGING:  BULK PACK

PITCH - MATING:  0.250" (6.35MM)

ROHS INFORMATION:  0010845090 CERT OF COMPLIANCE

ROW SPACING - MATING:  0.250" (6.35MM)

SERIES:  MLX? 42002

SHROUDING:  SHROUDED - 4 WALL

STANDARD PACKAGE:  520

STYLE:  BOARD TO CABLE/WIRE

TERMINATION:  SOLDER

APPLICATIONS:  AUTOMOTIVE GENERAL PURPOSE INDUSTRIAL
