ADDITIONAL FEATURE:  RELEASE TIME WITH DIODE

BODY BREADTH:  6 MM

BODY HEIGHT:  5.65 MM

BODY LENGTH OR DIAMETER:  10 MM

COIL CURRENT(DC)-MAX:  28 MA

COIL OPERATE VOLTAGE(DC):  3.75 V

COIL POWER:  140 MW

COIL RELEASE VOLTAGE(DC):  500 MV

COIL RESISTANCE:  178 O

COIL VOLTAGE(DC)-MAX:  5 V

COIL VOLTAGE-NOM:  5 V

COIL/INPUT SUPPLY TYPE:  DC

CONTACT (AC) MAX POWER RATING R LOAD:  62.5VA@250VAC

CONTACT (AC) MAX RATING R LOAD:  5A@250VAC

CONTACT (DC) MAX POWER RATING R LOAD:  60W@220VDC

CONTACT (DC) MAX RATING R LOAD:  5A@220VDC

CONTACT CURRENT(AC)-MAX:  5 A

CONTACT CURRENT(DC)-MAX:  5 A

CONTACT RESISTANCE:  50 MO

CONTACT VOLTAGE(AC)-MAX:  250 V

CONTACT VOLTAGE(DC)-MAX:  220 V

CONTACT/OUTPUT SUPPLY TYPE:  AC/DC

DIELECTRIC STRENGTH BETWEEN COIL AND CONTACTS:  1800 VRMS

DIELECTRIC STRENGTH BETWEEN OPEN CONTACTS:  1000 VRMS

ELECTRICAL LIFE:  100000 CYCLE(S)

END CONTACT MATERIAL:  PALLADIUM RUTHENIUM

END CONTACT PLATING:  GOLD ALLOY

INPUT POWER-MAX:  60 W

INPUT SWITCHING CONTROL TYPE:  RANDOM

INSERTION LOSS (MAX):  -0.03 DB

INSULATION RESISTANCE:  1 GO

ISOLATION-MAX:  -37 DB

MANUFACTURER:  TE CONNECTIVITY LTD

MANUFACTURER PART NUMBER:  1-1462037-4

MANUFACTURER SERIES:  1462037

MOUNTING FEATURE:  SURFACE MOUNT-STRAIGHT

NUMBER OF TERMINALS:  8

OPERATE TIME:  8 MS

OPERATING FREQUENCY-MAX:  900 MHZ

OPERATING FREQUENCY-MIN:  100 MHZ

OPERATING TEMPERATURE-MAX:  85 °C

OPERATING TEMPERATURE-MIN:  -40 °C

PACKAGE DESCRIPTION:  ROHS COMPLIANT

PACKING METHOD:  BOX; TAPE AND REEL

PBFREE CODE:  YES

PHYSICAL DIMENSION:  10MM X 6MM X 5.65MM

REFERENCE STANDARD:  UL

RELAY ACTION:  MOMENTARY

RELAY FORM:  2 FORM C

RELAY FUNCTION:  DPDT

RELAY TYPE:  RF RELAY

RELEASE TIME:  10 MS

SEALING:  IP67/RT5

SURFACE MOUNT:  NO

SWITCHING TIME:  18 MS

TERMINATION TYPE:  SOLDER

VSWR:  1.49

WEIGHT:  0.75 G
