5380598-3
PIN RECEPTACLE CONNECTOR 0.018" ~ 0.040" (0.46MM ~ 1.02MM) NO TAIL SOLDERCall for availability
Manufactured by:
Mfr Part#: 5380598-3
PACKAGING: BULK PACK
STANDARD PACKAGE: 2,000
Availability
Qty in Stock: Call for availability
Min. Order Qty: 1
ACCEPTS PIN DIAMETER: 0.018" ~ 0.040" (0.46MM ~ 1.02MM)
BOARD THICKNESS: 0.156" (3.96MM)
CATEGORIES: CONNECTORS, INTERCONNECTS
CONTACT FINISH: TIN
CONTACT FINISH THICKNESS: 80ΜIN (2.03ΜM)
CONTACT MATERIAL: BERYLLIUM COPPER
DETAILED DESCRIPTION: PIN RECEPTACLE CONNECTOR 0.018" ~ 0.040" (0.46MM ~ 1.02MM) NO TAIL SOLDER
FLANGE DIAMETER: 0.125" (3.18MM)
INSERTION FORCE: 0.12N ~ 0.34N
LEAD FREE STATUS / ROHS STATUS: LEAD FREE / ROHS COMPLIANT
LENGTH - OVERALL: 0.262" (6.65MM)
MANUFACTURER: TE CONNECTIVITY AMP CONNECTORS
MANUFACTURER PART NUMBER: 5380598-3
MANUFACTURER STANDARD LEAD TIME: 12 WEEKS
MOISTURE SENSITIVITY LEVEL (MSL): 1 (UNLIMITED)
MOUNTING HOLE DIAMETER: 0.086" ~ 0.089" (2.18MM ~ 2.26MM)
OPERATING TEMPERATURE: -65°C ~ 126°C
PACKAGING: BULK PACK
PIN HOLE DIAMETER: 0.048" (1.22MM)
ROHS INFORMATION: 5380598-3 STATEMENT OF COMPLIANCEROHS 2 STATEMENT
SOCKET DEPTH: 0.145" (3.68MM)
STANDARD PACKAGE: 2,000
TAIL TYPE: NO TAIL
TERMINATION: SOLDER
