FAMILY:  F/FAST

JESD-30 CODE:  R-GDFP-F20

LENGTH:  13.716 MM

LOGIC IC TYPE:  BUS DRIVER

MANUFACTURER:  TEXAS INSTRUMENTS

MANUFACTURER PART NUMBER:  54F374FMQB

NUMBER OF BITS:  8

NUMBER OF FUNCTIONS:  1

NUMBER OF PORTS:  2

NUMBER OF TERMINALS:  20

OPERATING TEMPERATURE-MAX:  125 °C

OPERATING TEMPERATURE-MIN:  -55 °C

OUTPUT CHARACTERISTICS:  3-STATE

OUTPUT POLARITY:  TRUE

PACKAGE BODY MATERIAL:  CERAMIC, GLASS-SEALED

PACKAGE CODE:  DFP

PACKAGE DESCRIPTION:  CERAMIC, FP-20

PACKAGE SHAPE:  RECTANGULAR

PACKAGE STYLE:  FLATPACK

PART PACKAGE CODE:  DFP

PIN COUNT:  20

PROPAGATION DELAY (TPD):  11 NS

SCREENING LEVEL:  MIL-STD-883

SEATED HEIGHT-MAX:  2.286 MM

SUPPLY VOLTAGE-MAX (VSUP):  5.5 V

SUPPLY VOLTAGE-MIN (VSUP):  4.5 V

SUPPLY VOLTAGE-NOM (VSUP):  5 V

SURFACE MOUNT:  YES

TECHNOLOGY:  TTL

TEMPERATURE GRADE:  MILITARY

TERMINAL FINISH:  NOT SPECIFIED

TERMINAL FORM:  FLAT

TERMINAL PITCH:  1.27 MM

TERMINAL POSITION:  DUAL

WIDTH:  6.731 MM
