LM26480SQ-AA/NOPB

LM26480SQ-AA/NOPB

Call for availability

Manufactured by:

TEXAS INSTRUMENTS

Mfr Part#:  LM26480SQ-AA/NOPB

PACKAGE / CASE:  24-WFQFN EXPOSED PAD

PACKAGING:  REEL

STANDARD PACKAGE:  1,000

SUPPLIER DEVICE PACKAGE:  24-WQFN (4X4)

Availability

  • Qty in Stock: Call for availability

  • Min. Order Qty: 1

SPECIFICATION

CATEGORIES:  INTEGRATED CIRCUITS (ICS)

FREQUENCY - SWITCHING:  2MHZ

FUNCTION:  ANY FUNCTION

LEAD FREE STATUS / ROHS STATUS:  LEAD FREE / ROHS COMPLIANT

MANUFACTURER:  TEXAS INSTRUMENTS

MANUFACTURER PART NUMBER:  LM26480SQ-AA/NOPB

MANUFACTURER PRODUCT PAGE:  LM26480SQ-AA/NOPB SPECIFICATIONS

MANUFACTURER STANDARD LEAD TIME:  7 WEEKS

MOISTURE SENSITIVITY LEVEL (MSL):  1 (UNLIMITED)

MOUNTING TYPE:  SURFACE MOUNT

NUMBER OF OUTPUTS:  4

OPERATING TEMPERATURE:  -40°C ~ 85°C

PACKAGE / CASE:  24-WFQFN EXPOSED PAD

PACKAGING:  REEL

STANDARD PACKAGE:  1,000

SUPPLIER DEVICE PACKAGE:  24-WQFN (4X4)

TOPOLOGY:  STEP-DOWN (BUCK) SYNCHRONOUS (2), LINEAR (LDO) (2)

VOLTAGE - SUPPLY:  2.8 V ~ 5.5 V

VOLTAGE/CURRENT - OUTPUT 1:  0.8 V ~ 2 V, 1.5A

VOLTAGE/CURRENT - OUTPUT 2:  1 V ~ 3.3 V, 1.5A

VOLTAGE/CURRENT - OUTPUT 3:  1 V ~ 3.5 V, 300MA

W/LED DRIVER:  NO

W/SEQUENCER:  NO

W/SUPERVISOR:  NO
