4N26-X009T
OPTOISOLATOR TRANSISTOR WITH BASE OUTPUT 5000VRMS 1 CHANNEL 6-SMDCall for availability
Manufactured by:
Mfr Part#: 4N26-X009T
PACKAGE / CASE: 6-SMD, GULL WING
PACKAGING: REEL
STANDARD PACKAGE: 1
SUPPLIER DEVICE PACKAGE: 6-SMD
Availability
Qty in Stock: Call for availability
Min. Order Qty: 1
CATEGORIES: ISOLATORS
CURRENT - DC FORWARD (IF) (MAX): 60MA
CURRENT - OUTPUT / CHANNEL: 50MA
CURRENT TRANSFER RATIO (MIN): 20% @ 10MA
DETAILED DESCRIPTION: OPTOISOLATOR TRANSISTOR WITH BASE OUTPUT 5000VRMS 1 CHANNEL 6-SMD
INPUT TYPE: DC
LEAD FREE STATUS / ROHS STATUS: LEAD FREE / ROHS COMPLIANT
MANUFACTURER: VISHAY SEMICONDUCTOR OPTO DIVISION
MANUFACTURER PART NUMBER: 4N26-X009T
MANUFACTURER STANDARD LEAD TIME: 7 WEEKS
MOISTURE SENSITIVITY LEVEL (MSL): 1 (UNLIMITED)
MOUNTING TYPE: SURFACE MOUNT
NUMBER OF CHANNELS: 1
OPERATING TEMPERATURE: -55°C ~ 100°C
OUTPUT TYPE: TRANSISTOR WITH BASE
PACKAGE / CASE: 6-SMD, GULL WING
PACKAGING: REEL
RISE / FALL TIME (TYP): 2ΜS, 2ΜS
STANDARD PACKAGE: 1
SUPPLIER DEVICE PACKAGE: 6-SMD
VCE SATURATION (MAX): 500MV
VOLTAGE - FORWARD (VF) (TYP): 1.36V
VOLTAGE - ISOLATION: 5000VRMS
VOLTAGE - OUTPUT (MAX): 70V
ALTERNATE PARTS: 4N26-X009
